Active Control of Flexible Structures deals with vibration control for flexible structures which are or may be the subject of a broadband primary vibration field. The authors present a complete rationale for solving the problem, from experimental structural characterization to controller implementation. In reaching this objective the following steps are addressed:
experimental identification of the dynamic model of the structure;
optimal placement of sensors and actuators;
formulation of control constraints in terms of controller frequency response shape, based on specification and characteristics of sensors and actuators;
controller design and simulation; and
controller implementation and rapid prototyping.
The experimental identification procedure is based on a gray-box approach tailored to the estimation of modal parameters of flexible structures. The actuator/sensor placement algorithm maximizes a modal controllability index so as to improve the effectiveness of the control action. Taking into account the physical limitations of sensors and actuators, the controller is chosen as a stable, band-pass MIMO system resulting from the closed-form solution of a robust control problem. The closed-form solution is particularly attractive for large-scale control systems, overcoming possible numerical problems caused by ill-conditioned solutions. Experimental results on an aeronautical stiffened skin panel are presented using rapid-prototyping hardware.
Active Control of Flexible Structures will be of interest to academics and practising engineers working on vibration-reduction problems in aerospace and other transportation environments and to civil engineers concerned with seismic vibration in buildings. Graduate students taking courses in mechanical, aeronautical and control engineering, particularly when involved with smart structures and actuators, will be informed by this book.
Advances in Industrial Control aims to report and encourage the transfer of technology in control engineering. The rapid development of control technology has an impact on all areas of the control discipline. The series offers an opportunity for researchers to present an extended exposition of new work in all aspects of industrial control.
Recenzijas
From the reviews:
Intended for graduate students and practicing engineers, this book treats vibration control for structural systems. It addresses identification of the dynamic model of the structure, placement of sensors and actuators, formulation of control constraints, controller design and simulation, and controller implementation and rapid prototyping. The material is based on the authors work on two projects financed by the European Community in the 5th and 6th Framework programs. (IEEE Control Systems Magazine, February, 2012)
