Advanced Automotive Fault Diagnosis: Automotive Technology: Vehicle Maintenance and Repair 5th editionPalielināt
  • Formāts: Hardback, 418 pages, height x width: 276x219 mm, weight: 930 g, 58 Tables, color; 33 Line drawings, color; 96 Line drawings, black and white; 391 Halftones, color; 39 Halftones, black and white; 424 Illustrations, color; 135 Illustrations, black and white
  • Izdošanas datums: 23-Sep-2020
  • Izdevniecība: Routledge
  • ISBN-10: 0367330547
  • ISBN-13: 9780367330545
Citas grāmatas par šo tēmu:
Permanent link: https://www.kriso.lv/db/9780367330545.html
Keywords:
"Learn all the skills you need with this book to pass Level 3 and 4 Vehicle Diagnostic courses from IMI, City and Guilds and BTEC, as well as ASE, AUR, and other higher-level qualifications"--

Diagnostics: Test don’t guess.

Learn all the skills you need to pass Level 3 and 4 Vehicle Diagnostics courses from IMI, City & Guilds, and BTEC, as well as ASE, AUR, and other higher-level qualifications.

Along with 25 new real-life case studies, this fifth edition of Advanced Automotive Fault Diagnosis includes new content on diagnostic tools and equipment: VCDS, decade boxes, scanners, pass through, sensor simulators, break out boxes, multimeter updates for HV use, and more . It explains the fundamentals of vehicle systems and components, and it examines diagnostic principles and the latest techniques employed in effective vehicle maintenance and repair. Diagnostics, or faultfinding, is an essential part of an automotive technician's work, and as automotive systems become increasingly complex there is a greater need for good diagnostic skills.

Ideal for students, included throughout the text are useful definitions, key facts, and ‘safety first’ notes. This text will also assist experienced technicians to further improve their performance and keep up with recent industry developments.

Recenzijas

An excellent addition to any lecturer/trainer/mentor and apprentice/learner in the process of learning about automotive faults.

-- Carl Smith, Suffolk New College, UK
